£1,099.00
The audiolab 7000A improves on the 6000A with a genuine 70W per channel output.
A new DAC, a new full-colour IPS LCD screen and more!
Whatever the input source – the 7000A has been crafted to the same level of detail one has come to expect from Audiolab.
Dual analogue inputs cater for CD players and line-level sources.
Dual Coax and SPDIF inputs expand this for the digital sources.
HDMI input for television audio.
The 7000A also delivers full decoding of MQA, the hi-res streaming technology
Improved phono stage for moving magnet phono cartridges.
The built in Bluetooth aptX receiver serves up a solution for wireless audio playback and smart devices.
| General Description | Integrated Amplifier |
| Design Philosophy and Core Technology | – 2 x 70W (8 ohms) / 2 x 110W (4 ohms) Class AB – ES9038Q2M 32-bit DAC – 2.8″ (480x640mm) Full View IPS LCD – Built in Certified Hardware MQA Full Decoder (PC USB, Coax / Optical) – Bluetooth 5.0 (aptX / aptX LL) Support – Low Noise Moving Magnet Phono Stage – Dedicated Current-Feedback Headphone amp – Integrated / PRE-POWER / PRE only Modes – VU Digital / VU Analogue Meter – USB Upgrade Support |
| Inputs | 3 x Analogue, 1 x Phono (MM), 1 x Power Amplifier, 2 x SPDIF (Coax), 2 x SPDIF (Optical), 1 x HDMI ARC, 1 x PC USB (USB B – Windows / mac OS only), 1 x Bluetooth (aptX/aptX LL), 1 x 12V Trigger |
| Outputs | 1 x PRE Amplifier, 1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger |
| Sampling Frequency | Optical / Coaxial: 44.1kHz – 192kHz; PC USB: 44.1kHz-768kHz (PCM) / DSD64, DSD128, DSD256, DSD512 |
| Preamplifier Section | |
| Gain | +6dB (Line); +55dB (Phono MM) |
| Input Sensitivity | 820mV (Line, Volume = 0dB); 3.1mV (Phone MM, Volume = 0dB) |
| Input Impedance | 10K (Line); 47K // 100pF (Phono MM) |
| Total Harmonic Distortion (THD) | < 0.0005% (1kHz @ 2V, Volume = 0dB) |
| Frequency Response | 20Hz-20kHz (+/-0.1dB) |
| Output Voltage | 2.3V max. (Volume = 0dB) |
| Output Impedance | 100 ohms |
| Signal-to-Noise Ratio | > 110dB (Line, A-weighted); > 76dB (Phono MM, A-weighted |
| DAC | |
| D to A Converter | ES9038Q2M |
| Total Harmonic Distortion (THD) | < 0.0005% (1KHz @ 0dBFS) |
| Output Level (0dBFS, 1kHz) | 2.1Vrms |
| Max. Sampling Frequency | Optical, Coaxial: 192kHz; PC USB: PCM768kHz, DSD512 |
| Power Amplifier Section | |
| Gain | +29dB |
| Rated Power Output | 2 x 70W (8 ohms, THD<1%); 2 x 110W (4 ohms, THD<1%) |
| Frequency Response | 20Hz-20kHz (+/-0.3dB) |
| Total Harmonic Distortion (THD) | <0.003% (1kHz @ 40W / 8 ohms) |
| Input Sensitivity | 720mV |
| Signal-to-Noise Ratio (S/N) | > 110dB (A-weighted) |
| Max. Output Current | 9A |
| Headphone Amplifier | |
| Total Harmonic Distortion (THD) | < 0.01% (1kHz, 50mW) |
| Output Impedance | 10 ohms |
| Load Impedance | 20-600 ohms |
| General | |
| Standby Power Consumption | <0.5W |
| Net Weight | 8.4kg |
| Gross Weight | 10.7kg |
| Dimensions (mm) (W x D x H) | 444 x 340 x 78 |
| Carton Size (mm) (W x D x H) | 500 x 455 x 140 |
| Finish | Black / Silver |
| Power Requirements | 220-240V ~ 50/ 60Hz; |
| (depending on region) | 100-120V ~ 50/ 60Hz |
| Standard Accessories | Power Cord, Remote Control, User Manual, Antennas, etc. |
| Weight | 10.5 kg |
|---|---|
| Dimensions | 47 × 51 × 16 cm |
| Colour | Black, Silver |
