Description
The award winning Wharfedale DIAMOND 12.3 floor standing speaker.
With enhanced presence and power, the DIAMOND 12.3 is refined and the perfect, affordable floorstanding speaker for 2-channel hi-fi systems.
Just as great acting as the front pair of a seriously impressive home theatre system.
Configured in a 2.5 way system with exception crossover technology, the DIAMOND 12.3 utilises dual 130mm Klarity drivers for impactful yet refined mid-range and bass frequencies.
While the 25mm dome tweeter delivers open and smoothly extended high frequencies.
Specification
General description | 2.5-way floorstanding speaker |
---|---|
Enclosure type | bass reflex |
Bass driver | 5″(130mm) advanced PP Cone |
Midrange driver | 5″(130mm) advanced PP Cone |
Treble driver | 1″(25mm) Textile Dome |
AV shield | No |
Sensitivity(2.83V @ 1m) | 89dB |
Recommended amplifier power | 30-150W |
Peak SPL | 102dB |
Nominal impedance | 8Ω Compatible |
Minimum impedance | 5Ω |
Frequency response(+/-3dB) | 45Hz ~ 20kHz |
Bass extension(-6dB) | 40Hz |
Crossover frequency | 2.2kHz |
Cabinet Volume (in litres) | 26.6L |
Dimensions ( H x W x D ) | (925+50) x 180 x (320+28) mm |
