Description
To celebrate its history, Wharfedale has established the Heritage Series recreations of famous models from its past, entirely re-engineered using contemporary techniques and materials.
The original Linton debuted in 1965 and the line continued in various iterations until the end of the 1970s.
It was a classic model of its time, viewed as a serious hi-fi speaker but also relatively affordable.
Its cabinet was substantial, big enough to hold three drive units including a good-sized bass unit, yet not overly unwieldy by the standards of the day.
The new Linton has a clear family resemblance.
It, too, is a three-way standmount model – a rarity in the modern era – retaining similar proportions to the classic Linton models.
Its wood-veneered cabinet has a vintage look, yet the standard of finish is distinctly contemporary.
A new modern classic.
Specification
General Description | 3-way vented-box/standmount |
---|---|
Enclosure Type | Bass reflex |
Transducer Complement | 3-way |
Bass Driver | 8″(200mm) black woven Kevlar® cone |
Midrange Driver | 5″(135mm) black woven Kevlar® cone |
Treble Driver | 1″ (25mm) soft dome |
AV Shield | No |
Sensitivity (2.83v @1m) | 90dB |
Recommended Amplifier Power | 25-200W |
Peak SPL | 110dB |
Nominal Impedance | 6Ω |
Minimum Impedance | 3.5Ω |
Frequency Response(+/-3dB) | 40Hz ~ 20kHz |
Bass Extension(-6dB) | 35Hz |
Crossover Frequency | 630Hz & 2.4kHz |
Height (on plinth) | 565mm |
Width | 300mm |
Depth (with terminals) | (330+30)mm |
